Understanding DSEAR – Area Classification & Hazardous Substances

July 30, 2015
Clock Icon 5 min read

Working around explosive atmospheres and hazardous substances can be extremely unsafe – that’s a given. But simply knowing that they can pose a threat isn’t enough; an awareness alone will not stop one stray spark from igniting something flammable. You need to know about the appropriate preventive methods and must be adequately equipped to combat your workplace’s threats. This is why DSEAR exists.


What is DSEAR?

dsear_precuations

DSEAR stands for the Dangerous Substances and Explosive Atmospheres Regulations 2002, which require employers to control the risks that fire, explosive atmospheres, and dangerous substances pose to people’s safety whilst at work. It enables all workplaces to stamp out the embers that are these risks, so they can be confident and careful when carrying out their day-to-day, work-related activities.

All manner of materials can lead to a devastating outbreak of fire or an explosion – even things you’d probably never deem a hazard. That’s what often makes controlling them not only tricky, but absolutely vital. Whether it’s the most obvious dangers – such as volatile gases – or the most seemingly unthreatening component – such as flour – all substances which could instigate a fire or explosion should have both eyes closely kept upon them.

Your workplace might contain more dangerous materials and risks than you think. But don’t worry; part of DSEAR’s purpose is to familiarise you with them; to make you alert; to help you deal with them responsibly.

expert icon

Need a Course?

Our DSEAR Training provides you with a full introduction to the requirements of the regulations and will ensure you understand the risks from dangerous substances and explosive atmospheres, know how to carry out a risk assessment, and can implement suitable workplace control measures.


What are Dangerous Substances?

fire_explosions_dsear

If you’ve ever seen the very conspicuous ‘FLAMMABLE’ label on a can of hairspray or on the side of a paint bucket, then you’ve seen a dangerous substance. There could be copious amounts around workplaces and employees may even handle them on a daily basis.

DSEAR defines dangerous substances as any substance (or mixtures, called ‘preparations’) that could start a fire or explosion – when exposed to a source of ignition and air – and cause people harm.

They come in the form of:

  • Dangerous liquids – e.g. petrol, solvents, paints, adhesives, and cleaning chemicals. They emit flammable vapours which could be set alight or explode in the air.
  • Gases – e.g. liquefied petroleum gas and methane that are typically stored in pressurised cylinders. In the instance that they escape, the gas could ignite and explode on a catastrophic scale.
  • Chemicals – e.g. cleaning chemicals, which are often unstable and could react violently with other materials or under certain conditions.
  • Dusts – which could be produced by work activities and materials, e.g. coal, woodworking, sugar and flour in the food industry, animal feed, and metal powders in factories. Clouds of dust raised by these can explode very violently if ignited.
  • Solids – e.g. packaging materials and textiles. These can be especially dangerous if they give off acrid black smoke when exposed to a source of ignition, as it can be poisonous and therefore not only a danger to people’s safety, but also their health.

Even if you are not in an industry that directly handles dangerous substances, there will be some all around you. Cleaning chemicals are in virtually every kitchen space; paint is on practically every wall (which will cause fire to spread easily and even release flammable gases when burning); and some form of packaging materials or textiles will be undoubtedly present in 99% of workplaces.

Proper storage and safe handling of such materials is therefore imperative.


What is an Explosive Atmosphere?

chemical_fire_dsear

When certain dangerous substances mix together in the air, an explosive atmosphere is formed. Once ignition occurs in that atmosphere, combustion will spread to the entire unburned mixture. Simply put, an explosive atmosphere is a room or space filled with combustible gases, vapours, mists, or dusts and a potential source of ignition. It’s an atmosphere that has the necessary components to cause an explosion.

It is both difficult but absolutely crucial to control the release or build-up of flammable and combustible materials. DSEAR stipulates that, when workplace activities or the substances handled are likely to create an explosive atmosphere, they must be adequately controlled.

However, as mentioned earlier, you have to do more than simply adopt a one-size-fits-all mentality where control measures are concerned. This is especially true of industries that will deal directly with dangerous substances. A DSEAR risk assessment will help you spot the hazards associated with explosive atmospheres and dangerous substances and should take into account the workplace’s activities, size, location, and other specific details.

If the employer discovers that the workplace contains potentially explosive atmospheres, they must ensure that they are classified into zones. This will help them minimize the risks posed by explosive atmospheres.


What are the DSEAR Hazard Zones?

dsear_hazard_zones_precuations

Without knowing why your environment is at risk of explosions, how can you hope to prevent it? The purpose of zoning – also known as area classification – is to ensure employers thoroughly consider the risks posed by explosive atmospheres in relation to work equipment, sources of ignition, and correct warning signage.

Area classification is a method of analysing and classifying an environment in which explosive gas atmospheres could build up – which are then labelled as hazardous areas. Hazardous areas are defined by DSEAR as “any place in which an explosive atmosphere may occur in quantities such as to require special precautions to protect the safety of workers”. Such special precautions would be necessary in areas where the use of certain equipment could be extremely dangerous, for example.

The following three zones cover dangerous gases, vapours, and mists:

  • Zone 0 – A place in which an explosive atmosphere consisting of a mixture with air of dangerous substances in the form of gas, vapour or mist is present continuously or for long periods or frequently.
  • Zone 1 – A place in which an explosive atmosphere consisting of a mixture with air of dangerous substances in the form of gas, vapour or mist is likely to occur in normal operation occasionally.
  • Zone 2 – A place in which an explosive atmosphere consisting of a mixture with air of dangerous substances in the form of gas, vapour or mist is not likely to occur in normal operation but, if it does occur, will persist for a short period only.

The following three zone descriptions cover areas where hazardous dusts are present:

  • Zone 20 – A place in which an explosive atmosphere in the form of a cloud of combustible dust in air is present continuously, or for long periods or frequently.
  • Zone 21 – A place in which an explosive atmosphere in the form of a cloud of combustible dust in air is likely to occur in normal operation occasionally.
  • Zone 22 – A place in which an explosive atmosphere in the form of a cloud of combustible dust in air is not likely to occur in normal operation but, if it does occur, will persist for a short period only.

After identifying zones, the employer can then properly select and install apparatus that will be safe for use in the explosive atmosphere. They can protect the classified hazard zones from coming into contact with sources of ignition, and can mark the entry points with appropriate warning signage. They can do their absolute best to prevent explosions from occurring and ensure the wellbeing of all their employees.
